Trident has an expertise in a wide range of mechanical BIM works, including but not limited to:
HVAC Design for Hydraulic Systems (Heating systems, Chilled Water systems etc.)
HVAC Design for Air Systems (Ventilation systems, Air Conditioning systems, etc.)
HVAC Design for Refrigerant-based Systems
Fire Protection Systems Design (Wet Fire Sprinklers systems, Dry Pipe systems, Dry Chemical Suppression systems etc.)
BIM 3D Model Creation for all types of Building Mechanical Systems
4D and 5D BIM in Construction for Mechanical Systems
Shop Drawings for Mechanical Systems and many more.
Depending on specific conditions of each project and with reference to it’s specifications we choose one of the multiple Revit templates, that will be the most compliant to the project. Then we start creating the BIM Model with various inputs i.e. Governmental Construction Codes and Byelaws, specification sheets, contract documents, equipment submittals, LEED application, standard region practices etc. What makes Trident special is that you are appreciated to overview the project status at any certain stage, and highly advised to join a weekly progress charette, including Project Managers, Senior Engineers, Architects and a Client Representative.
During the modeling we validate the design to ensure performance, optimization and maintenance. We help our clients with producing construction documentation for existing and new buildings, generate project schedules for them, as well as execute the MEP coordination of project designs with other disciplines.
Experienced engineers make sure adhering to the local mechanical building codes which are applicable to the project.
The final model is generated once all the clashes had been resolved, in order to avoid issues during the actual construction.
Finally, we generate shop-drawings for the purpose of installation and spool drawings for pre-fabrication elements to enable a proper installation process at construction site. Our portfolio in this field will be provided on request.
Don’t hesitate to contact us for any related query. You will always be welcome at Trident.
