Creating Revit families

Creating Revit families

Families are the main building blocks in Revit software, used for BIM modeling. A family is a group of elements with a common set of properties, called parameters, and a related graphical representation. Revit families can be parametric and non-parametric.

Parametric families have certain parameters to control elements and data of the family, the geometry of the family may be changed by using parameters. Non-parametric families accordingly show the only actual dimensions and properties of the certain element and don’t have an ability to be modified by changing family parameters.

On installation of Revit you get a basic standard library to use, which should be good enough to start modeling simple structures. Once you start building more complex structures, you’re likely to require further families creation.

We offer you a service of creating loadable Revit families, which may be related to the following:

• ARCHITECTURAL FAMILIES
• STRUCTURAL FAMILIES
• MEP FAMILIES
• EQUIPMENT FAMILIES
• CUSTOM FAMILIES

{"slide_to_show":"3","slide_to_scroll":"1","autoplay":"true","autoplay_speed":3000,"speed":300,"arrows":"true","dots":"false"}

We use technical data sheets, drawings, visualizations and other product information for families creation. The software used are Autodesk Revit and Autodesk Inventor. Cost and time required for creation will depend on complexity of family and LOD (Level of development) required, but anyway it will be a maximum cost effective proposal.

We will maintain the accuracy of your product’s dimensions and preserve its geometry and technical features. If you are looking to share and sell your products to the construction market, having then using Trident to build you custom made BIM families is a good marketing tool that lets your clients view and use your products virtually.

So don’t hesitate to contact us for any related query. You will always be welcome at Trident.
